PGA36120U44A - Square D - Molded Case Circuit Breaker
Overview
Product Specifications - PGA36120U44A - Square D Powerpact Circuit Breaker
-
Part Number:
PGA36120U44A -
Manufacturer:
-
Family:
Powerpact -
Pole:
3 -
Amp
1200 -
Volt:
600 -
Phase:
3
-
Category:
-
Connection:
I-Line Style Plug-In -
Type:
PGA -
Functions:
LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault -
Protection:
Solid State -
AIC Ratings:
35kA@480V
Dimensions
-
Dimensions (HxWxD):
16.16" x 8.05" x 8.27" -
Weight:
32 lbs
Standards
Product Description - PGA36120U44A - Square D Powerpact Circuit Breaker
Schneider Electric / Square D, Powerpact, type PGA, 3P, ABC phase connection, 3PH, 1200A, 600V, 35kA@480V, UL listed, standard interrupting capacity, i-line style plug-in, complete with micrologic interchangeable ammeter 6.0A trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, solid state electronic, molded case circuit breakers.
