LAL36125 - Square D - Molded Case Circuit Breaker
Overview
Product Specifications - LAL36125 - Square D Powerpact Circuit Breaker
-
Part Number:
LAL36125 -
Manufacturer:
-
Family:
LAL Series -
Pole:
3 -
Amp
125 -
Volt:
600 -
Phase:
3
-
Category:
-
Connection:
Feed-Thru -
Type:
LAL -
Functions:
LI - Long-Time and Instantaneous -
Protection:
Thermal Magnetic -
AIC Ratings:
30kA@480V
Dimensions
-
Dimensions (HxWxD):
11" x 6" x 5.84"
Standards
Additional Details
-
Frame Type:
J-Frame -
Trip Unit Technology:
Thermal-magnetic -
Line Rated Current:
125 Amp -
Mounting Mode:
Unit Mount
-
Electrical Connection:
Lugs line / Lugs load -
Magnetic Hold Current:
625 Amp
Product Description - LAL36125 - Square D Powerpact Circuit Breaker
Square D, LAL Series, type LAL, 3P, 3PH, 125A, 600V, 30kA@480V, standard interrupting capacity, feed-thru, complete with LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, thermal magnetic molded case circuit breakers.
Documentation
Select Condition
From $461.70
Original: $1,538.99
-70%LAL36125 - Square D - Molded Case Circuit Breaker—
$1,538.99
$461.70Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Overview
Product Specifications - LAL36125 - Square D Powerpact Circuit Breaker
-
Part Number:
LAL36125 -
Manufacturer:
-
Family:
LAL Series -
Pole:
3 -
Amp
125 -
Volt:
600 -
Phase:
3
-
Category:
-
Connection:
Feed-Thru -
Type:
LAL -
Functions:
LI - Long-Time and Instantaneous -
Protection:
Thermal Magnetic -
AIC Ratings:
30kA@480V
Dimensions
-
Dimensions (HxWxD):
11" x 6" x 5.84"
Standards
Additional Details
-
Frame Type:
J-Frame -
Trip Unit Technology:
Thermal-magnetic -
Line Rated Current:
125 Amp -
Mounting Mode:
Unit Mount
-
Electrical Connection:
Lugs line / Lugs load -
Magnetic Hold Current:
625 Amp
Product Description - LAL36125 - Square D Powerpact Circuit Breaker
Square D, LAL Series, type LAL, 3P, 3PH, 125A, 600V, 30kA@480V, standard interrupting capacity, feed-thru, complete with LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, thermal magnetic molded case circuit breakers.
