MG24546 - Square D - Molded Case
Overview
Product Specifications - MG24546 - Square D Molded Case Circuit Breakers
-
Part Number:
MG24546 -
Manufacturer:
-
Family:
Multi9 -
Pole:
3 -
Amp:
63 -
Volt:
240 -
Phase:
3
-
Category:
-
Connection:
Bolt-On -
Type:
MG -
Functions:
NGC -
Protection:
Thermal Magnetic -
AIC Ratings:
10kA@240V
Dimensions
-
Dimensions (HxWxD):
3.19 x 2.13 x 2.87 -
Weight:
0.73 lbs
Standards
Product Description - MG24546 - Square D Molded Case Circuit Breakers
Introducing the MG24546 from Schneider Electric's Multi9 series, also known as Square D. This miniature molded case circuit breaker, classified as type MG, is designed for three-phase applications. It offers a 63A capacity at 120/240V, with a standard interrupting capacity of 10kA at 240V. Featuring a Bolt-On design and D curve characteristics, it ensures reliable protection. Additionally, it is UL listed and CSA certified, suitable for reverse feed applications, and serves as a supplementary protector in electrical systems
