EHD1030L - Eaton - Molded Case Circuit Breaker

Product image 1

EHD1030L - Eaton - Molded Case Circuit Breaker

Overview

Product Specifications - EHD1030L - Eaton Molded Case Circuit Breaker

  • Part Number:

    EHD1030L

  • Manufacturer:

    Eaton Cutler-Hammer

  • Family:

    Series C

  • Pole:

    1

  • Amp

    30

  • Volt:

    277

  • Phase:

    1

  • Category:

    Molded Case / 1-Pole

  • Connection:

    Feed-Thru

  • Type:

    EHD

  • Functions:

    LI - Long-Time and Instantaneous

  • Protection:

    Thermal Magnetic

  • AIC Ratings:

    14kA@480V

  • Frame Type:

    F Frame

Dimensions

  • Dimensions (HxWxD):

    6" x 1.38" x 3.38"

  • Weight:

    2 lbs

Standards

CSA Approved logo

Product Description - EHD1030L - Eaton Molded Case Circuit Breaker

Cutler Hammer / Eaton / Westinghouse, Series C, type EHD, 1P, 1PH, 30A, 277V, 14kA@480V, standard interrupting capacity, 40 degree C, feed-thru, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, thermal magnetic, molded case circuit breakers

Documentation

PDF Icon Catalogue

PDF Icon Technical Specifications

PDF Icon Installation Instructions

Select Condition
From $34.50

Original: $114.99

-70%
EHD1030L - Eaton - Molded Case Circuit Breaker—

$114.99

$34.50
