ED3225L - Eaton - Molded Case Circuit Breaker
Overview
Product Specifications - ED3225L - Eaton Molded Case Circuit Breaker
-
Part Number:
ED3225L -
Manufacturer:
-
Family:
Series C -
Pole:
3 -
Amp
224 -
Volt:
240 -
Phase:
3
-
Category:
-
Connection:
Feed-Thru -
Type:
ED -
Functions:
LI - Long-Time and Instantaneous -
Protection:
Thermal Magnetic -
AIC Ratings:
65kA@240V -
Frame Type:
F Frame
Dimensions
-
Dimensions (HxWxD):
6" x 4.13" x 3.38"
-
Weight:
4.5 lbs
Standards
Product Description - ED3225L - Eaton Molded Case Circuit Breaker
Cutler Hammer / Eaton / Westinghouse, Series C, type ED, 3P, 3PH, 225A, 240V, 35kA@480V, standard interrupting capacity, 40 degree C, feed-thru, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, thermal magnetic, molded case circuit breakers
Documentation
Select Condition
From $149.40
Original: $497.99
-70%ED3225L - Eaton - Molded Case Circuit Breaker—
$497.99
$149.40Product Information
