800T-QT24G - Allen-Bradley 24V Volt Pilot Light

800T Pilot Light, Full V Type PTT W/ Incand Lam, Green Plastic Lens, 24 V AC/DC, Standard
Ruggedly attractive and boldly functional, the Allen-Bradley Bulletin 800T line of push buttons are designed and built to perform in demanding industrial environments. Catalog item 800T-QT24G from Rockwell Automation is a 24 V AC/DC, 30 mm pilot light. It is an incandescent lamp with a green plastic lens. And it is push-to-test and full voltage type. For full product details, please see the sections below. Allen-Bradley is a trademark of Rockwell Automation, Inc.

• Manufacturer: Allen-Bradley

Specifications

• Number of indicator lights: 1
• Contact block thermal current rating: 10 A
• Contact block utilization category (AC): A600, AC-15
• Illumination lamp type: Incandescent
• Contact block operational voltage, max: 600V AC, 600V DC
• Contact block utilization category (DC): Q600, DC-13
• Operator construction/material: Metal
• Illumination module type: Full voltage
• Illumination module input voltage: 24V AC/DC
• Suitable for illumination: Yes
• Hole diameter: 30.5 mm
• Type of electric connection: Screw connection
• Operator mechanical design life (cycles, min.): 250000
• Contact block electrical design life (cycles, at max. load): 1000000
• Enclosure compatibility (NEMA type): 1, 4, 12, 13
• Operator function: Push-to-test
• Operator type: Pilot light, with lamp test feature
• Vibration: 10 G maximum
• Shock: 25 G (contact fragility)/100 G (no damage)
• Contact block termination wire range: 14 - 18 AWG (x2)
• Illumination module termination wire range: 14 - 18 AWG (x2)
• Contact block termination tightening torque: 6 - 8 lb - in / 0.7 - 0.9 N-m
• Illumination module termination tightening torque: 6 - 8 lb - in / 0.7 - 0.9 N-m
• Terminations with finger safe covers: No
• Operator cap/button shape: Round
• Operator cap type: Fresnal
• Operator cap color: Green
• Operator cap/button material: Plastic
• Contact block configuration: 1-NO 1-NC standard contacts
• Operating temperature: -25 °C
• Hazardous location rating: No
• Humidity: 50 %
• Storage temperature: -40 °C
• Certifications: ABS, CCC, CE, CSA, EAC, GOST, UL
